Description

Features:

· Suitable for punching steel up to max. 10mm thickness

· Release lever in case of jamming

· Adjustable counterholder for the steel

· Includes 1 set of round punch die, diameter of choice

Technical information:

· Punching capacity: max. Ø22mm in 4mm thickness up to max. Ø10 at 10mm thickness (S235/S355)

· Free space between punch and die is 15mm

· Voltage: 230V / 50Hz

· Power: 1100W

· Hydraulic power: 15ton / 700bar

· Dimensions (mm): 625x113x202

· Weight: 13,6 kg
